Which laptop PCs do you recommend for Lumion 2023 and earlier versions?

Avatar
Arthur Roodenburg
  • Updated
Follow




Looking for information on hardware for Lumion 2024?  See these articles:



1. General recommendations

Important: Laptop graphics cards have a performance that can be approximately 40% less than a similar model for a desktop.  For example, an RTX 3080 for desktop has a PassMark of about 25,335. An RTX 3080 for a laptop has a PassMark of about 16,674.

The first step in choosing a laptop for Lumion is to determine the specifications needed depending on your Project requirements, along with other criteria such as mobility.

Please refer to our guide on system requirements for Lumion:



1.1: Graphics card

High-end Requirements: 16GB+

Examples of High-performance Laptop GPUs that are capable of handling High-end Projects:

  • RTX 4090 Laptop GPU (16GB)
  • RTX A5500 Laptop GPU (16GB)
  • RTX 3080Ti Laptop GPU (16GB)

Recommended Requirements: 10GB+

Examples of other High-performance laptop GPUs that meet the Recommended requirements:

  • RTX 4080 Laptop GPU (12GB)
  • Radeon RX 6850M XT (12GB)
  • RTX A4500/A5000 Laptop GPU (16GB)
  • RTX 3080 Laptop GPU (16GB)

Examples of mid-range laptop GPUs that come very close to the Recommended requirements:

  • RTX 4060/4070 Laptop GPU (8GB)
  • Radeon RX 7600M/7600M XT (8GB)
  • RTX A4000 Laptop GPU (16GB)
  • RTX 3070/3070 Ti Laptop GPU (8GB)
  • RTX 2080 Mobile (8GB)
  • Radeon RX 6700S/6800S (8GB)

Minimum Requirements: 6GB+

Examples of low-end laptop GPUs that meet the Minimum requirements:

  • RTX 4050 Laptop GPU (8GB)
  • RTX 3060 Laptop GPU (6GB)
  • RTX 2060/2070/2080 Max-Q (6-8GB)
  • RTX A2000/3000 Laptop GPU (6-8GB)
  • Radeon RX 7600S/7700S (8GB)
  • Radeon RX 6600M/6650M/6700M/6800M/6850M (6-12GB)

1.2: System memory

  • High-end requirements: 64GB+
  • Recommended requirements: 32GB+
  • Minimum requirements: 16GB+

1.3: Screen resolution

  • 1920x1080 pixels to ensure the best possible performance in Lumion.
  • Displays with a higher resolution will have a significant negative impact on the performance of Lumion.
  • If you are planning on using a 4K resolution screen (3840x2160) you will need a GTX 3080 graphics card (or better) for optimal performance.  Alternatively, please consider setting the screen resolution to 1920x1080 while using Lumion - or selecting a lower Editor Resolution on the Settings screen in Lumion.

1.4: Raytracing

Lumion 2023 now comes equipped with Raytracing capabilities, however, to use this feature, a graphics card that supports this technology is required.


EVGA - Articles - RTX. It's On.  mceclip2.png

Laptop GPUs that support this technology are marked with a * below.

Note that this is an optional feature. It's still possible to use Lumion 2023 even if your graphics card does not support Raytracing, you just won't be able to make use of this Effect.



2. Performance Levels for Laptops:

When considering a laptop, please check the PassMark for the graphics card at PassMark Software: High End Video Card Chart.  And see our notes in 1. General recommendations (above).

Here is a partial list of the highest-performing graphics cards for laptops (according to their PassMark score as of February 25, 2023).  The PassMark will change but the general order of performance may still be the same.



Laptop GPU Performance Chart
Card: PassMark: Meets requirements:
GeForce RTX 4090 Laptop GPU* 31568 High-end
GeForce RTX 4080 Laptop GPU* 25922 High-end
Radeon RX 6850M XT* 21792 Recommended
GeForce RTX 3080 Ti Laptop GPU* 20519 Recommended
GeForce RTX 4060 Laptop GPU*
 		20275 Recommended
RTX A5500 Laptop GPU*  18474 Recommended
GeForce RTX 3070 Ti Laptop GPU* 18396 Recommended
RTX A4500 Laptop GPU* 18007 Recommended
GeForce RTX 3080 Laptop GPU* 16666 Recommended
RTX A5000 Laptop GPU* 16132 Recommended
RTX A4000 Laptop GPU* 15659 Minimum (top of)
GeForce RTX 3070 Laptop GPU* 15453 Minimum (top of)
GeForce RTX 2080 (Mobile)* 15107 Minimum (top of)
Quadro RTX 5000 (Mobile)* 14832 Minimum (top of)
RTX A3000 12GB Laptop GPU* 14816 Minimum (top of)
Radeon RX 6800S* 14769 Minimum (top of)
GeForce RTX 2070 Super with Max-Q Design* 14132 Minimum (top of)
Quadro RTX 5000 with Max-Q Design* 13915 Minimum (top of)
Radeon RX 6700S* 13697 Minimum (top of)
GeForce RTX 2080 Super with Max-Q Design* 13685 Minimum (top of)
GeForce RTX 2080 with Max-Q Design* 13226 Minimum (top of)
Radeon RX 6700M* 13279 Minimum (top of)
Radeon RX 6650M*
 		13158 Minimum (top of)
GeForce RTX 3060 Laptop GPU* 13147 Minimum (top of)
Quadro RTX 4000 with Max-Q Design* 13029 Minimum (top of)
RTX A3000 Laptop GPU* 12687 Minimum
Quadro RTX 4000 (Mobile)* 12602 Minimum
Radeon RX 6600M*
 		12415 Minimum
GeForce RTX 2070 (Mobile)* 12354 Minimum
Radeon RX 6850M* 12274 Minimum
Radeon RX 6800M*
 		12137 Minimum
GeForce RTX 2070 with Max-Q Design* 11933 Minimum
Quadro M6000 24GB* 11879 Minimum
GeForce GTX 1080 with Max-Q Design
 		11483 Minimum
GeForce RTX 2060 (Mobile)* 11355 Minimum
RTX A2000 8GB Laptop GPU* 10998 Minimum
GeForce GTX 1070 (Mobile) 10465 Minimum
GeForce GTX 1660 Ti (Mobile) 10176 Minimum
RTX A2000 Laptop GPU* 10176 Minimum
GeForce GTX 1070 with Max-Q Design 10020 Minimum
GeForce RTX 2060 with Max-Q Design* 9753 Minimum
Radeon Pro 5600M
 		9281 Minimum
Quadro M5000* 9254 Minimum
Quadro P4000 with Max-Q Design*
 		9083 Minimum

*Supports Raytracing

Refer to PassMarks for other laptop graphics cards, not on this list.



3. Laptop product suggestions:

These suggestions were updated on February 2023.

Some laptops can be configured with different components.  For example, if there is 32GB of System Memory (RAM) you might be able to increase it to 64GB.  See a retailer's website near you.

Some retailers such as ASUS, also have some models that can be configured for the graphics card.


3.1: High-End options:
  • ASUS ROG Strix Scar 16 (2023)
    16", Intel Core i9, 32GB RAM, NVIDIA RTX 4090 16GB, 2TB SSD.
  • MSI Stealth 17 Studio
    17.3", Intel Core i9, 64GB RAM, NVIDIA RTX 4090 16GB, 2TB SSD.
  • AORUS 17X
    17.3", Intel Core i9-13900HX, 32GB RAM, NVIDIA RTX 4090 8GB,  2TB SSD.
  • MSI - Raider GE77 HX:
    17.3", Intel Core i9, 32GB RAM, NVIDIA RTX 3080Ti 16GB, 1TB SSD.
  • Razer Blade 14/15/17:
    14/15.6/17.3", Ryzen 9 6900HX, 16GB RAM, NVIDIA RTX 3080Ti 16GB, 1TB SSD.
  • MSI CreatorPro Z16P:
    16", Intel Core i7-12700H, 64GB RAM, NVIDIA RTX A5500 16GB, M.2 2280 2TB SSD.



3.2: Recommended options:

RTX 4070/4080 laptops:

  • Razer Blade 18
    18", Intel Core i9-13950HX, 32GB RAM, NVIDIA RTX 4080 12GB,  1TB SSD.
  • Alienware M16
    16", Intel Core i9-13900HX, 16GB RAM, NVIDIA RTX 4080 12GB,  2TB SSD.
  • AORUS 17H
    17.3", Intel Core i7-13700H, 32GB RAM, NVIDIA RTX 4080 12GB,  1TB SSD.
  • Samsung Galaxy Book3
    16", Intel Core i9-13900H, 32GB RAM, NVIDIA RTX 4070 8GB,  1TB SSD.
  • GIGABYTE AERO 16
    16", Intel Core i9-13900H, 32GB RAM, NVIDIA RTX 4070 8GB,  1TB SSD.

RTX A3000/A4000/4500/A5000 laptops:

  • Dell New Precision 7760 Workstation (various configurations for RAM, memory):
    17.3", i5-11500H, 64GB RAM, NVIDIA RTX A5000 16GB, M.2 2280 2TB SSD.
  • Ultimate Precision 7670 Workstation:
    16", Intel Core i7-12850HX, 64GB RAM, NVIDIA RTX A4500 16GB, 1TB SSD.
  • HP ZBook Fury 17 G8:
    17.3", Intel Core i7-11850H, 32GB RAM, NVIDIA RTX A4000 16GB, 1TB SSD.
  • Dell New Precision 7760 Workstation:
    17.3", 64 GB RAM, i7-11850H, NVIDIA RTX A4000 8 GB, 512GB SSD.
  • Laptop ASUS ProArt StudioBook:
    16", Intel Core i7 11800H, 32GB RAM, NVIDIA RTX A3000 12GB, 1TB SSD.

Radeon RX 6850M XT Laptops:

  • Lenovo Legion 7 Gen 7:
    16", Ryzen 9 6900HX, 32GB RAM, AMD Radeon RX 6850M XT 16GB, 2TB SSD.
  • Alienware m17 R5 Gaming Laptop:
    17.3", Ryzen 9 6900HX, 64GB RAM, AMD Radeon RX 6850M XT 16GB, 1-4TB SSD.

RTX 3080 Laptops:

Note: Check if the graphics card configuration is the 8GB or 16GB model.  We recommend the 16GB model where possible for Recommended (or possibly High-End) Projects.

  • ASUS G533QS-HF009T:
    15.6", 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3080 (assume 8GB).
  • ASUS ROG Strix Scar 17 (G733QS-HG026T):
    17.3", 64GB RAM, 1TB SSD, NVIDIA GeForce RTX 3080 8GB.
  • Dell Alienware X15  (configure):
    15.6", 32GB RAM, Intel Core i9 11900H, NVIDIA GeForce RTX 3080 8GB, 4TB (2x 2TB) M.2 SSD.
  • MSI GE66 Raider 10UH-016NL:
    15.6", 32GB RAM, NVIDIA GeForce RTX 3080 8GB or 16GB option - 2TB SSD.
  • MSI GE76 Raider 10UH-202NL:
    17.3", 32GB RAM, NVIDIA GeForce RTX 3080 (16GB)  - 2TB m.2 SSD.
  • Gigabyte AORUS 15G YC:
    15.6", 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3080 8GB.
  • Asus ROG Zephyrus G15 GA503QS-HQ003T:
    15.6", 32GB DDR4-3200, 1TB SSD, NVIDIA GeForce RTX 3080 8 GB.
  • ASUS ROG Strix SCAR 15 G533QS-HF009T:
    15.6", 32GB RAM, NVIDIA GeForce RTX 3080 16GB, 2TB SSD.
  • MSI GS66 Stealth 10UH-056NL:
    15.6", 32GB RAM/64GB RAM, 2TB SSD, NVIDIA GeForce RTX 3080 8GB or 16GB.

RTX 3070/3070Ti Laptops:

  • ASUS ROG Strix SCAR 15 G533ZW-XS96:
    15.6", Intel Core i9-12900H, 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070Ti 8GB.
  • MSI - Vector Gaming Laptop:
    15.6", Intel Core i7HX, 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070Ti 8GB.
  • Acer - Predator Helios 300:
    15.6", Intel Core i7HX, 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070Ti 8GB.
  • Razer Blade 15 Gaming Laptop:
    15.6", 12th Gen Intel 14-Core i7, 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070Ti 8GB.
  • Dell Alienware X15  (configure):
    15.6", 32GB RAM, i7 11800H, NVIDIA GeForce RTX 3070 8GB, 1TB M.2 SSD.
  • Gigabyte AERO 15 OLED XC:
    15.6", 32GB RAM, Intel Core i7-10870H, 1TB SSD, NVIDIA GeForce RTX 3070 8 GB.
  • Gigabyte AERO 17 HDR XC:
    17.3", 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070 8GB.
  • Medion Erazer Beast X25:
    17.3", 32GB RAM, 1TB SSD, NVIDIA GeForce RTX 3070 8GB.

Radeon RX 6700S/6800S Laptops:

  • Legion Slim 7 Gen 7:
    16", 16GB RAM, AMD Ryzen™ 7 6800H, AMD RX 6800S 8GB, 1TB M.2 SSD.
  • ASUS Zephyrus 14:
    14", 16GB RAM, AMD Ryzen™ 7 6800H, AMD RX 6800S 8GB, 1TB M.2 SSD.
  • ROG Zephyrus G14 :
    14", 16GB RAM, AMD Ryzen™ 7 6900HS, AMD RX 6800S 8GB, 1TB M.2 SSD.

RTX 2080 series Laptops:

    • Laptop Razer Blade 15:
      15.6”, Intel Core i7, 16GB RAM, NVIDIA GeForce RTX 2080, 1TB SSD.
    • Acer Predator Triton 500:
      15.6”, Intel Core i7, 32GB RAM, NVIDIA GeForce RTX 2080, 1TB SSD.
    • Laptop Lenovo ThinkPad P15 G1:
      15.6”, Intel Core i7 10750H, 16GB RAM, NVIDIA GeForce RTX 2080, 512TB SSD.
3.3: Minimum requirement options:
RTX 4050/4060 laptops:

  • MSI Raider GE68:
    16", Intel Core i9-13980HX, 16GB RAM, 1 TB SSD - GeForce RTX 4060 6GB.

  • MSI Summit 16
    16", Intel Core i7, 32GB RAM, GeForce RTX 4060, 8GB, 1 TB SSD
  • Acer Nitro 5
    16", Intel Core i5-12500H, 32GB RAM, GeForce RTX 4050, 6GB, 1 TB SSD
  • MSI Cyborg 15
    16", Intel Core i7, 32GB RAM, GeForce RTX 4050, 6GB, 1 TB SSD

RTX 3060 laptops:

  • Asus ROG Zephyrus G14 GA401QM-K2023T:
    14", 32GB RAM, 1 TB SSD - GeForce RTX 3060 Max-Q 8GB, 1 TB SSD

  • Dell G16:
    16", Intel Core i7, 16GB RAM, GeForce RTX 3060, 6GB, 1 TB SSD
  • HP OMEN:
    16.1",12th Gen Intel Core i9-12900H, 16GB RAM, GeForce RTX 3060 6GB, 1 TB SSD
  • MSI - Sword:
    15.6", Intel Core i7, 16GB RAM, GeForce RTX 3060 6GB, 1 TB SSD

RTX 2070 laptops:

  • ASUS ROG Strix Hero III(2019):
    15.6”, 16GB RAM, NVIDIA GeForce RTX 2070, Intel Core i7-9750H, 512GB SSD.
  • ASUS ROG Strix Scar 15 (2020):
    15.6”, 16GB RAM, NVIDIA GeForce RTX 2070 Super, Intel Core i7-10875H, 1TB SSD.
  • ASUS ROG GU502GW-AH76 Zephyrus M Thin and Portable:
    15.6”, 16GB RAM, NVIDIA GeForce RTX 2070, Intel Core i7-9750H, 1TB SSD.

RTX 2060 laptops:

  • Asus ROG Strix G15 15.6" FHD 240Hz:
    15.6", 32GB RAM, Intel Core i7-10870H, 2048GB SSD, NVIDIA GeForce RTX 2060 6GB.
  • Acer Predator Helios 300 17.3" FHD IPS 144Hz Premium:
    17.3", 32GB RAM, Intel Core i7-10750H, 1TB SSD, NVIDIA GeForce RTX 2060 6GB.
  • Dell Alienware X15  (configure):
  • 15.6", 16GB, RAM, i7 11800H, NVIDIA GeForce RTX 3060 6GB, 256GB M.2 NVMe SSD.
  • Asus ROG Strix G15 GL 15.6" FHD 240Hz:
    15.6", 24GB RAM, Intel 8-Core i7-10870H, 1TB SSD, NVIDIA GeForce RTX 2060 6GB    .
  • ROG Zephyrus G15 (2020) Ultra Slim:
    15.6”, 16GB RAM,AMD Ryzen 7 4800HS, GeForce RTX 2060, 1TB NVMe SSD.
  • ASUS ROG Zephyrus M15 15.6" 4K Ultra HD (3840 x 2160):
    15.6", 16GB RAM, Intel Core i7-10750H, 1TB SSD, NVIDIA GeForce RTX 2060.
  • Acer Predator Helios 300:
    17.3", 16GB RAM, Intel i7-10750H, NVIDIA GeForce RTX 2060 6GB, 1TB SSD.

RTX A2000/A3000 series Laptops:

  • Dell New Precision 7760 Workstation:
    17.3", 32GB RAM, i7-11850H, NVIDIA RTX A3000 6GB, 512 GB, SSD.
  • MSI - CreatorPro M16:
    16", Intel Core i7, 32GB RAM, i7-11850H, NVIDIA RTX A2000 6GB, 1TB SSD.

Radeon RX 6000M series Laptops:

  • MSI Delta:
    15.6", 16GB RAM, AMD Ryzen 7, AMD RX 6700M 8GB, 1TB SSD
  • HP OMEN AMD Advantage Edition:
    15.6", 16GB RAM, AMD Ryzen 7 6800H, AMD RX 6650M 8GB, 1TB SSD
  • ASUS ROG Strix G15 Advantage Edition:
    15.6", 16GB RAM, AMD Ryzen 7, AMD RX 6800M 10GB, 512GB     SSD
  • CORSAIR Voyager a1600:
    16", 32GB RAM,AMD Ryzen R9 6900HS, AMD RX 6800M 10GB, 2TB SSD
  • MSI Alpha 17:
    17.3", 16GB RAM, AMD Ryzen 7 5800H, AMD RX 6800M 8GB, 512GB     SSD
  • HP Omen 16:
    16.1", 16GB RAM, AMD Ryzen R9 6800H, AMD RX 6650M 8GB, 1TB SSD



*These are suggestions, there are other makes and models that might also suit, we are not recommending these products, simply offering advice on some hardware that may work with Lumion, especially as we have not tested each of these.



See also:









Related articles

Comments

0 comments

Article is closed for comments.
